Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
General Specifications
| Net Power | 303.00 hp (225.95 kw) Starting 2023 Model Year |
|---|---|
| Operating Weight | 51,124 (23,190) Starting 2024 Model Year |
| Operating Weight lbs (kg) | 51,124 (23,190) Starting 2025 Model Year |
| Bucket Capacity | 3.75 - 15.5 (2.8 - 11.9) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.75 - 15.5 (2.8 - 11.9) Starting 2025 Model Year |
| Engine type | Cat C9.3B Starting 2024 Model Year |
| Engine Power | 321 (239) Starting 2024 Model Year |
| OperatingWeight lbs. (kg) | 51,124 (23,190) Starting 2026 Model Year |
| Travel Speed(Fwd/Rev) | 24.5 / 24.5 mph Starting 2025 Model Year |
| Engine Power Net hp (kW) | 321 (239) Starting 2025 Model Year |
| Tip Load | 32,727 (14,845) Starting 2024 Model Year |
| Engine | C9.3B Starting 2023 Model Year |
| Breakout Force | 36,974.00 lbs ft (50,129.35 nm) Starting 2023 Model Year |
| Full-Turn Tipping Load | 32,233.00 lbs (14,620.66 kg) Starting 2023 Model Year |
| Travel Speed | 24.5 / 24.5 mph Starting 2024 Model Year |
| Tip Load lbs. (kg) | 32,727 (14,845) Starting 2025 Model Year |
