Caterpillar
980G
- Operating Weight
- 65,638 lb
- Bucket Capacity - heaped
- 5.49 yd³
- Gross Power
- 300.0 hp
- Net Power
- 323.0 hp
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 65,638 lb |
|---|---|
| Fuel Capacity | 124.2 gal |
| Hydraulic System Fluid Capacity | 55.0 gal |
| Static Tipping Weight | 44,767 lb |
| Engine Oil Fluid Capacity | 10.0 gal |
| Breakout Force | 47,277 lb |
| Static Tipping Load - Full Turn | 40,005 lb |
| Dump Clearance | 130 in |
Engine
| Engine Model | Cat 3406C DITA |
|---|---|
| Displacement | 891 in³ |
| Gross Power | 300.0 hp |
| Net Power | 323.0 hp |
| Flywheel Power | 300.0 hp |
| Maximum Flywheel Power | 300.0 hp |
Weights
| Operating Weight | 65,078 lb |
|---|
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 3.4 s |
| Dump Time | 2.0 s |
| Hydraulic Cycle Time - Dump | 2.0 s |
| Hydraulic Cycle Time - Total | 12.2 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 3.4 s |
| Hydraulic Cycle Time - Raise | 6.8 s |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 149 in |
| Width Over Tires | 128 in |
| Reach at Max Lift and Dump | 61 in |
| Length with Bucket on Ground | 373 in |
Transmission
| Max Speed - Forward | 23.3 mph |
|---|---|
| Max Speed - Reverse | 26.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Forward - 1 | 4.4 mph |
| Reverse - 1 | 5.0 mph |
| Forward - 2 | 7.7 mph |
| Reverse - 2 | 8.7 mph |
| Forward - 3 | 13.5 mph |
| Reverse - 3 | 15.3 mph |
| Forward - 4 | 23.3 mph |
| Reverse - 4 | 26.6 mph |
| Travel Speed | 23.2 mph |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Dump Clearance at Max Raise | 130 in |
| Breakout Force | 47,277 lb |
| Bucket Width | 137 in |
| Maximum Bucket Capacity | 7.49 yd³ |
Service Refill Capacities
| Cooling System | 20.9 gal |
|---|---|
| Transmission | 16.4 gal |
| Crankcase | 10.1 gal |
| Differential - Final Drives - Front | 23.0 gal |
| Differential - Final Drives - Rear | 21.4 gal |
| Hydraulic Tank | 33.1 gal |
| Fuel Tank - Standard | 124.0 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Trunnion |
| Maximum Single-Wheel Rise and Fall | 22 in |
