Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Bucket Capacity Range | 6.5 - 13.5 yd |
|---|---|
| Rated Bucket Capacity | 7.00 – 10.01 yd³ |
| Cat Truck Match - High Lift | 772 |
| Cat Truck Match - Standard | 770 |
Engine
| Engine Model | Cat C15 ACERT |
|---|---|
| Displacement | 927 in³ |
| Net Power | 409.0 hp |
| Make | Cat |
| Stroke | 7 in |
| Bore | 5 in |
| Torque Rise | 37.0 % |
| Gross Power - SAE J1995 | 449.0 hp |
| Net Power - ISO 9249 | 409.0 hp |
| Net Power - SAE J1349 | 409.0 hp |
| Rated Speed | 1,800 rpm |
| Emissions | Tier 2 |
| EEC 80/1269 | 409.0 hp |
| Gross Power - ISO 14396 | 441.0 hp |
| Peak Torque - 1,200 rpm | 1,711 lb-ft |
Transmission
| Transmission Type | Cat planetary power shift |
|---|---|
| Forward - 1 | 5.0 mph |
| Reverse - 1 | 5.0 mph |
| Forward - 2 | 8.0 mph |
| Reverse - 2 | 8.0 mph |
| Direct Drive - Forward 2 | 8.0 mph |
| Direct Drive - Forward 3 | 14.0 mph |
| Direct Drive - Reverse 2 | 9.0 mph |
| Direct Drive - Reverse 3 | 16.0 mph |
| Direct Drive - Forward 4 | 24.0 mph |
Brakes & Steering
| Brakes | SAE J1473 OCT90 ISO 3450:1992 |
|---|
Bucket
| Bucket Capacities | 13.50 yd³ |
|---|
General Specifications
| Operating Weight lbs (kg) | 93,090 (42,225) — Starting 2016 Model Year |
|---|---|
| Bucket Capacity cu. yd. (cu m) | 7.0 - 10.0 (5.4 - 7.6) — Starting 2016 Model Year |
| Engine type | Cat C15 ACERT — Starting 2016 Model Year |
| Max Dump Height ft.( m) | 6.6 (2.0) — Starting 2016 Model Year |
| Engine Power HP (KW) | 409 (305) — Starting 2016 Model Year |
Service Refill Capacities
| Transmission | 20.0 gal |
|---|---|
| Crankcase | 9.0 gal |
| Differential - Final Drives - Front | 49.0 gal |
| Differential - Final Drives - Rear | 45.0 gal |
| Hydraulic System - Tank Only | 33.0 gal |
| Hydraulic System Factory Fill | 87.0 gal |
| Cooling Systems | 24.0 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Trunnion |
| Oscillation Angle | 13 ° |
Hydraulic Cycle Times
| Rack Back | 4.5 s |
|---|---|
| Lower Float Down | 4.3 s |
Hydraulic System - Lift/Tilt
| Lift Cylinder - Bore | 8 in |
|---|---|
| Lift Cylinder - Stroke | 45 in |
| Lift/Tilt System - Circuit | Load Sense |
| Relief Valve Setting - Lift/Tilt | 4,050 psi |
| Lift/Tilt System - Pump | 2 110 cc variable displacement |
| Maximum Flow at 2,165 rpm | 123.0 gal/min |
Hydraulic System - Steering
| Steering System - Circuit | Load Sense |
|---|---|
| Steering System - Pump | Piston variable displacement |
| Steering Cut Off Pressure | 4,000 psi |
| Total Steering Angle | 70 ° |
