Caterpillar
BOMAG
815-2
Asphalt Paver
13 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Screed | 25,993 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Hydraulic System Fluid Capacity | 50.0 gal |
| Cooling System Fluid Capacity | 8.4 gal |
Engine
| Engine Model | 3054TA |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 121.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Length of Track on Ground | 89 in |
|---|---|
| Transport Width | 130 in |
| Transport Height | 89 in |
| Track Width | 14 in |
| Length w/ Screed | 222 in |
Hopper/Paver
| Paving Width - max | 240 in |
|---|---|
| Paving Speed - max | 2.5 mph |
| Hopper Capacity | 7 lb |
| Travel Speed - max | 5.0 mph |
| Auger Diameter | 16 in |
