Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Operating Weight w/ Screed | 15,699 lb |
|---|---|
| Fuel Capacity | 20.0 gal |
| Hydraulic System Fluid Capacity | 17.0 gal |
| Operating Voltage | 12 V |
Engine
| Net Power | 80.0 hp |
|---|---|
| Number of Cylinders | 4 |
Dimensions
| Transport Width | 102 in |
|---|---|
| Transport Height | 72 in |
| Length w/ Screed | 161 in |
| Width w/ Hopper Open | 120 in |
Hopper/Paver
| Paving Width - max | 192 in |
|---|---|
| Paving Speed - max | 1.6 mph |
| Travel Speed - max | 3.3 mph |
| Auger Diameter | 9 in |
| Paving Thickness - max | 6 in |
Comparable machines
Other asphalt pavers in a similar weight class.
