Caterpillar
Roadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Screed | 26,901 lb |
|---|---|
| Fuel Capacity | 50.0 gal |
| Hydraulic System Fluid Capacity | 50.0 gal |
| Cooling System Fluid Capacity | 5.1 gal |
Engine
| Engine Model | 3054DIT |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 107.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Wheelbase | 93 in |
|---|---|
| Transport Width | 96 in |
| Transport Height | 103 in |
| Tire Size | 13X22 Solid Rubber 16x24 sand rib |
| Length w/ Screed | 256 in |
Hopper/Paver
| Paving Width - max | 240 in |
|---|---|
| Paving Speed - max | 2.8 mph |
| Hopper Capacity | 7 lb |
| Travel Speed - max | 11.9 mph |
| Auger Diameter | 16 in |
