Caterpillar
Komatsu
D65PX-17
Crawler Dozer
27 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 126,567 lb |
|---|---|
| Fuel Capacity | 270.3 gal |
| Hydraulic Fluid Capacity | 28.6 gal |
Engine
| Engine Model | 3412 |
|---|---|
| Displacement | 1,648 in³ |
| Gross Power | 520.0 hp |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 107.8 gal/min |
|---|---|
| Relief Valve Pressure | 2,698 psi |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Height - Top of Cab | 168 in |
| Length of Track on Ground | 152 in |
| Width Over Tracks | 131 in |
| Length w/ Blade | 306 in |
| Length w/o Blade | 221 in |
Transmission
| Max Speed - Forward | 7.8 mph |
|---|---|
| Max Speed - Reverse | 9.7 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 17 psi |
|---|---|
| Track Gauge | 101 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 7,332 in³ |
Standard Blade
| Width | 192 in |
|---|---|
| Height | 81 in |
| Capacity | 22.50 yd³ |
