Caterpillar
New Holland
D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 30,821 lb |
|---|---|
| Fuel Capacity | 30.2 gal |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Gross Power | 62.0 hp |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 67 in |
| Length of Track on Ground | 72 in |
| Width Over Tracks | 71 in |
| Length w/ Blade | 145 in |
| Length w/o Blade | 109 in |
Transmission
| Max Speed - Forward | 7.1 mph |
|---|---|
| Max Speed - Reverse | 3.2 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 1 |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 56 in |
| Number of Track Rollers per Side | 5 |
| Standard Shoe Size | 12 in |
| Ground Contact Area | 1,721 in³ |
General Specifications
| Net Power | 104.00 hp (77.55 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 21,150.00 lbs (9,593.49 kg) Starting 2021 Model Year |
| Weight lbs (kg) | 20,640 (9,362) Starting 2025 Model Year |
| Engine type | Cat C3.6 Starting 2024 Model Year |
| Engine Power HP (KW) | 104 (77.6) Starting 2024 Model Year |
| Engine | C3.6 Starting 2023 Model Year |
| Blade Capacity | 2.86.3.06 cu yd Starting 2023 Model Year |
| Blade Cap. | 2.86.3.06 cu yd Starting 2021 Model Year |
