New Holland
Case
1150H WT
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 32,761 lb |
|---|---|
| Fuel Capacity | 71.4 gal |
| Cooling System Fluid Capacity | 6.7 gal |
| Final Drives Fluid Capacity | 6.9 gal |
| Engine Oil Capacity | 3.8 gal |
| Hydraulic Fluid Capacity | 16.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | 6BTAA5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 140.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo-aftercooler |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 479 lb-ft |
Hydraulic System
| Relief Valve Pressure | 2,756 psi |
|---|---|
| Pump Type | Variable Displacement Pump |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 101 in |
| Width Over Tracks | 95 in |
| Length w/ Blade | 187 in |
| Length w/o Blade | 144 in |
Transmission
| Max Speed - Forward | 6.9 mph |
|---|---|
| Max Speed - Reverse | 8.1 mph |
| Transmission Type | Full PowerShift CounterShaft Constant Mesh |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 76 in |
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 43 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 39,525 in³ |
Standard Blade
| Width | 126 in |
|---|---|
| Height | 43 in |
| Capacity | 4.09 yd³ |
| Blade Angle (both directions) | 10 ° |
