D3C LGP II

Specifications

62 data points

Operating Specifications specifications
Operating Weight	17,170 lb
Fuel Capacity	32.0 gal
Cooling System Fluid Capacity	5.3 gal
Final Drives Fluid Capacity	3.2 gal
Engine Oil Capacity	3.2 gal
Hydraulic Fluid Capacity	15.0 gal
Operating Voltage	12 V
Alternator Supplied Amperage	40 A

Undercarriage specifications
Ground Pressure	4 psi
Track Gauge	66 in
Number of Track Rollers per Side	5
Number of Shoes per Side	39
Standard Shoe Size	25 in
Ground Contact Area	4,051 in³

S-Series specifications
Gross Power	70.0 hp
Operating Weight	18,942 lb
Max Speed - Forward	6.8 mph
Max Speed - Reverse	7.1 mph
Displacement	317 in³
Engine Model	3,204
Fuel Capacity	30.2 gal
Ground Clearance	12 in
Ground Contact Area	7,518 in³
Height	29 in
Height - Top of Cab	108 in
Length of Track on Ground	97 in
Length w/ Blade	166 in
Length w/o Blade	134 in
Number of Forward Gears	3
Number of Reverse Gears	3
Number of Track Rollers per Side	7
Standard Shoe Size	39 in
Track Gauge	79 in
Transmission Type	powershift
Width	110 in
Width Over Tracks	119 in
Capacity	1.60 yd³
Ground Pressure	3 psi
