Caterpillar
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 10,860 lb |
|---|---|
| Fuel Capacity | 30.0 gal |
| Cooling System Fluid Capacity | 11.0 gal |
| Final Drives Fluid Capacity | 1.8 gal |
| Engine Oil Capacity | 3.8 gal |
Engine
| Displacement | 350 in³ |
|---|---|
| Gross Power | 48.0 hp |
| Net Power | 43.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 70 in |
| Length of Track on Ground | 62 in |
| Width Over Tracks | 78 in |
| Length w/o Blade | 124 in |
Transmission
| Max Speed - Forward | 5.4 mph |
|---|---|
| Max Speed - Reverse | 1.9 mph |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
Undercarriage
| Track Gauge | 60 in |
|---|---|
| Number of Shoes per Side | 31 |
| Standard Shoe Size | 13 in |
| Ground Contact Area | 1,589 in³ |
General Specifications
| Net Power | 130.00 hp (96.94 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 29,258.00 lbs (13,271.22 kg) Starting 2021 Model Year |
| Weight lbs (kg) | 29,259 (13,271.7) Starting 2024 Model Year |
| Engine type | Cat C4.4 Starting 2024 Model Year |
| Engine Power HP (KW) | 130 (96.9) Starting 2024 Model Year |
| Engine | C4.4 Starting 2023 Model Year |
| Blade Capacity | 4.98 cu yd Starting 2023 Model Year |
| Blade Cap. | 4.98 cu yd Starting 2021 Model Year |
