Caterpillar

D4K XL

Crawler Dozer

Operating Weight
17,961 lb
Max Speed - Forward
5.6 mph
Gross Power
92.0 hp
Net Power
84.0 hp
All crawler dozers
Caterpillar D4K XL Crawler Dozer
1 / 5
Image 1 of 5
Image: binghamfarmmachinery.com

Specifications

38 data points

Operating Specifications

Operating Specifications specifications
Operating Weight17,961 lb
Fuel Capacity51.5 gal
Cooling System Fluid Capacity6.0 gal
Final Drives Fluid Capacity2.6 gal
Engine Oil Capacity3.0 gal
Hydraulic Fluid Capacity15.7 gal
Operating Voltage12 V
Alternator Supplied Amperage120 A

Engine

Engine specifications
Engine ModelC4.4 ACERT
Displacement269 in³
Power Measured @1,900 rpm
Gross Power92.0 hp
Net Power84.0 hp
Number of Cylinders4
MakeCat

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity19.4 gal/min
Relief Valve Pressure2,988 psi

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab108 in
Length of Track on Ground90 in
Width Over Tracks79 in
Length w/ Blade169 in
Length w/o Blade130 in

Transmission

Transmission specifications
Max Speed - Forward5.6 mph
Max Speed - Reverse6.2 mph
Transmission TypeHydrostatic
Number of Forward Gears2
Number of Reverse Gears2

Undercarriage

Undercarriage specifications
Ground Pressure6 psi
Track Gauge61 in
Number of Track Rollers per Side7
Number of Shoes per Side43
Standard Shoe Size18 in
Ground Contact Area3,206 in³

Standard Blade

Standard Blade specifications
Width110 in
Height40 in
Capacity2.60 yd³
Blade Angle (both directions)25 °
