Caterpillar
Komatsu
D53P-17
Crawler Dozer
14 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 45,415 lb |
|---|---|
| Fuel Capacity | 101.2 gal |
Engine
| Engine Model | 3306 |
|---|---|
| Displacement | 641 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 165.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 84 in |
| Length of Track on Ground | 103 in |
| Width Over Tracks | 97 in |
| Length w/ Blade | 202 in |
| Length w/o Blade | 161 in |
Transmission
| Max Speed - Forward | 7.7 mph |
|---|---|
| Max Speed - Reverse | 10.0 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 6 |
| Standard Shoe Size | 22 in |
| Ground Contact Area | 4,518 in³ |
Standard Blade
| Width | 133 in |
|---|---|
| Height | 50 in |
| Capacity | 5.10 yd³ |
