Caterpillar
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 41,914 lb |
|---|---|
| Fuel Capacity | 101.0 gal |
Engine
| Engine Model | 3306T |
|---|---|
| Displacement | 537 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 185.0 hp |
| Number of Cylinders | 6 |
| Flywheel Power | 175.0 hp |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 111 in |
| Width Over Tracks | 97 in |
| Length w/ Blade | 202 in |
| Length w/o Blade | 161 in |
Transmission
| Max Speed - Forward | 7.7 mph |
|---|---|
| Max Speed - Reverse | 10.0 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 85 in |
| Number of Track Rollers per Side | 7 |
| Standard Shoe Size | 22 in |
| Ground Contact Area | 4,888 in³ |
| Ground Clearance | 2 in |
Standard Blade
| Width | 133 in |
|---|---|
| Height | 50 in |
| Capacity | 3.90 yd³ |
