Caterpillar

D7R II WH

Crawler Dozer

Operating Weight
61,500 lb
Max Speed - Forward
6.6 mph
Gross Power
258.0 hp
Net Power
240.0 hp
All crawler dozers
Caterpillar D7R II WH Crawler Dozer
1 / 5
Image 1 of 5
Image: micoequipment.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight61,500 lb
Fuel Capacity126.5 gal
Operating Voltage24 V
Alternator Supplied Amperage95 A

Engine

Engine specifications
Engine Model3176C
Displacement639 in³
Power Measured @2,100 rpm
Gross Power258.0 hp
Net Power240.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab135 in
Length of Track on Ground113 in
Width Over Tracks102 in
Length w/ Blade185 in
Length w/o Blade186 in

Transmission

Transmission specifications
Max Speed - Forward6.6 mph
Max Speed - Reverse8.4 mph
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Ground Pressure11 psi
Track Gauge78 in
Number of Track Rollers per Side7
Number of Shoes per Side43
Standard Shoe Size22 in
Ground Contact Area5,016 in³

Standard Blade

Standard Blade specifications
Width146 in
Capacity18.40 yd³
