Caterpillar
Liebherr
PR732B L
Crawler Dozer
18 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 70,504 lb |
|---|---|
| Fuel Capacity | 169.1 gal |
Engine
| Engine Model | D342 |
|---|---|
| Displacement | 1,245 in³ |
| Gross Power | 300.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 134 in |
| Length of Track on Ground | 125 in |
| Width Over Tracks | 110 in |
| Length w/ Blade | 259 in |
| Length w/o Blade | 207 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.4 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 13 psi |
|---|---|
| Track Gauge | 84 in |
| Number of Track Rollers per Side | 5 |
| Standard Shoe Size | 22 in |
| Ground Contact Area | 5,456 in³ |
Standard Blade
| Width | 159 in |
|---|
