Liebherr
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 42,329 lb |
|---|---|
| Fuel Capacity | 99.1 gal |
| Cooling System Fluid Capacity | 15.6 gal |
| Final Drives Fluid Capacity | 4.8 gal |
| Engine Oil Capacity | 5.9 gal |
| Hydraulic Fluid Capacity | 47.1 gal |
Engine
| Engine Model | D 926 T-E |
|---|---|
| Displacement | 610 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 173.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 128 in |
| Length of Track on Ground | 163 in |
| Width Over Tracks | 100 in |
Undercarriage
| Number of Track Rollers per Side | 6 |
|---|---|
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 1 |
