Caterpillar
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 87,045 lb |
|---|---|
| Fuel Capacity | 199.0 gal |
Engine
| Engine Model | 3408 |
|---|---|
| Displacement | 1,099 in³ |
| Gross Power | 335.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 152 in |
| Length of Track on Ground | 127 in |
| Width Over Tracks | 126 in |
| Length w/ Blade | 246 in |
| Length w/o Blade | 196 in |
Transmission
| Max Speed - Forward | 7.4 mph |
|---|---|
| Max Speed - Reverse | 9.2 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 101 in |
|---|---|
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 36 in |
| Ground Contact Area | 9,099 in³ |
Standard Blade
| Width | 165 in |
|---|---|
| Height | 71 in |
| Capacity | 14.40 yd³ |
