Caterpillar
Komatsu
D65PX-17
Crawler Dozer
27 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 114,656 lb |
|---|---|
| Fuel Capacity | 255.0 gal |
Engine
| Engine Model | 3412 |
|---|---|
| Displacement | 1,648 in³ |
| Gross Power | 460.0 hp |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Height - Top of Cab | 167 in |
| Length of Track on Ground | 141 in |
| Width Over Tracks | 126 in |
| Length w/ Blade | 280 in |
| Length w/o Blade | 210 in |
Transmission
| Max Speed - Forward | 7.6 mph |
|---|---|
| Max Speed - Reverse | 9.4 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 17 psi |
|---|---|
| Track Gauge | 100 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 6,696 in³ |
Standard Blade
| Width | 179 in |
|---|
