Caterpillar
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
51 data points
Engine
| Engine Model | Cat C7.1 ACERT |
|---|---|
| Displacement | 428 in³ |
| Net Power | 169.0 hp |
| Number of Cylinders | 6 |
| Bore | 4 in |
| Stroke | 5 in |
| Maximum Torque - 1,400 rpm | 612 lb-ft |
| Ratings | 1,550 rpm |
| Engine Power - Maximum Gross - ISO 14396 | 173.5 hp |
| Note | *Metric values. |
| Engine Power - Maximum Net - ISO 9249/SAE J1349 | 169.0 hp |
| Engine Gross Power (Maximum) - ISO 14396 | 174.0 hp |
Weights
| One-Piece Boom - Front and Rear Outriggers | 43,321 lb |
|---|---|
| VA Boom - Front and Rear Outriggers | 44,423 lb |
| VA Boom - Rear Dozer, Front Outriggers | 43,982 lb |
| One-Piece Boom - Rear Dozer, Front Outriggers | 42,880 lb |
Hydraulic System
| Maximum Flow - Auxiliary Circuit - Medium Pressure | 12.9 gal/min |
|---|---|
| Maximum Pressure - Auxiliary Circuit - High Pressure | 5,076 psi |
| Maximum Pressure - Implement Circuit - Heavy Lift | 5,366 psi |
| Maximum Pressure - Implement Circuit - Normal | 5,076 psi |
| Tank Capacity | 40.4 gal |
| Maximum Pressure - Implement Circuit - Normal and Travel Circuit | 5,076 psi |
| Swing Mechanism | 4,496 psi |
Transmission
| Creeper Speed - 1st Gear | 1.9 mph |
|---|---|
| Creeper Speed - 2nd Gear | 7.5 mph |
| Forward/Reverse - 1st Gear | 6.2 mph |
| Forward/Reverse - 2nd Gear | 21.7 mph |
| Maximum Gradeability | 64.0 % |
| Maximum Forward/Reverse - 2nd Gear | 22.0 mph |
Undercarriage
| Ground Clearance | 16 in |
|---|---|
| Oscillation Axle Angle | 9 ° |
Tires & Wheels
| Standard | 10.00-20 (Dual Pneumatic) |
|---|---|
| Optional | 1) 11.00-20 (Dual Pneumatic); 2) 445/70/R19.5 TL XF (Single Pneumatic); 3) 10.00-20 (Dual Solid Rubber) |
Bucket
| Bucket Capacities | 1.54 yd³ |
|---|
General Specifications
| Net Power | 169.00 hp (126.03 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 45,525.00 lbs (20,649.82 kg) Starting 2021 Model Year |
| Engine | C7.1 ACERT Starting 2021 Model Year |
| Max Travel Speed | 22.00 mph (35.41 kph) Starting 2021 Model Year |
Drive System
| Maximum Travel Speed | 22.0 mph |
|---|
Service Refill Capacities
| Cooling System | 12.4 gal |
|---|---|
| Engine Crankcase | 4.9 gal |
| Front Steering Axle - Differential | 2.8 gal |
| Powershift Transmission | 0.7 gal |
| Rear Axle - Housing (Differential) | 3.7 gal |
| Final Drive | 0.7 gal |
| Diesel Exhaust Fluid Tank | 9.1 gal |
| Fuel Tank - Total Capacity | 109.6 gal |
Swing Mechanism
| Swing Torque | 35,403 lb-ft |
|---|---|
| Maximum Swing Torque | 424,836 in |
Working Ranges
| Maximum Digging Depth | 250 in |
|---|---|
| Maximum Reach - Ground Level | 377 in |
