Caterpillar
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 9,600 lb |
|---|---|
| Max Speed | 11.0 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | pneumatic |
Engine
| Engine Model | S4S |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,300 rpm |
| Torque Measured @ | 1,800 rpm |
| Power | 59.0 hp |
| Fuel Type | diesel |
| Torque | 135 lb-ft |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 67 in |
| Overall Width | 50 in |
| Turning Radius | 95 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 108 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 131 in |
Mast
| Load Capacity | 6,614 lb |
|---|---|
| Load Center | 20 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 1.1 mph |
| Max Fork Spread | 39 in |
