Caterpillar
Dynapac
PL2000S
Cold Planer
19 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight - Full Load | 66,359 lb |
|---|---|
| Travel Speed | 3.7 mph |
| Fuel Capacity | 290.6 gal |
| Water Spray System Fluid Capacity | 924.6 gal |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
| Inside Turn Radius | 78 in |
| Maximum Travel Speed | 3.6 mph |
| Engine Oil Capacity | 17.0 gal |
Engine
| Displacement | 1,105 in³ |
|---|---|
| Power Measured @ | 1,900 rpm |
| Net Power | 564.0 hp |
Dimensions
| Shipping Height | 125 in |
|---|---|
| Shipping Length | 296 in |
| Operating Length | 550 in |
| Max Operating Height | 156 in |
| Max Truck Clearance | 181 in |
| Minimum Operating Height | 126 in |
| Maximum Operating Height | 151 in |
| Operating Length - Conveyor Up | 547 in |
| Shipping Maximum Height | 124 in |
| Shipping Length - Base Machine | 294 in |
| Maximum Truck Clearance | 180 in |
| Shipping Length - With Conveyor Folded | 448 in |
Service Refill Capacities
| Fuel Tank Capacity | 290.0 gal |
|---|---|
| Water Spray System | 924.9 gal |
Conveyor System
| Discharge Conveyor Width | 32 in |
|---|---|
| Collecting Conveyor Width | 32 in |
| Discharge Conveyor Swing (R/L) | 48 ° |
| Collecting Conveyor Speed | 11.2 mph |
| Discharge Conveyor Maximum Speed | 11.2 mph |
| Discharge Conveyor Swing - From Center | 48 ° |
Rotary Cutter
| Cutting Depth | 13 in |
|---|---|
| Number of Tools | 178 |
| Tool Spacing | 1 in |
Rotor Assembly
| Maximum Cutting Depth | 13 in |
|---|
