CaterpillarCaterpillar
PR1000C
Cold Planer
18 specifications
Caterpillar
PM201
- Operating Weight - Full Load
- 86,360 lb
- Cutting Width
- 83 in
- Displacement
- 1,105 in³
- Gross Power
- 650.0 hp
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Operating Weight - Full Load | 86,360 lb |
|---|---|
| Operating Speed | 1.5 mph |
| Travel Speed | 3.7 mph |
| Fuel Capacity | 250.0 gal |
| Water Spray System Fluid Capacity | 999.9 gal |
| Shipping Weight - Empty | 76,950 lb |
| Hydraulic System Fluid Capacity | 180.0 gal |
| Operating Voltage | 24 V |
| Inside Turn Radius | 185 in |
| Maximum Travel Speed | 3.7 mph |
| Cooling System Fluid Capacity | 21.0 gal |
| Engine Oil Capacity | 17.0 gal |
Engine
| Engine Model | C18 with ACERT |
|---|---|
| Displacement | 1,105 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 650.0 hp |
| Net Power | 625.0 hp |
Weights
| Operating Weight - With Full Water Tank | 86,360 lb |
|---|---|
| Operating Weight - With Full Water Tank on Front Tracks | 47,500 lb |
| Operating Weight - With Full Water Tank on Rear Tracks | 38,860 lb |
| Shipping Weight - With Empty Water Tank | 76,950 lb |
| Shipping Weight - With Empty Water Tank on Front Tracks | 41,550 lb |
| Shipping Weight - With Empty Water Tank on Rear Tracks | 35,400 lb |
Dimensions
| Shipping Height | 127 in |
|---|---|
| Shipping Length | 325 in |
| Shipping Width | 102 in |
| Operating Length | 595 in |
| Operating Width | 110 in |
| Max Operating Height | 199 in |
| Max Truck Clearance | 187 in |
| Minimum Operating Height | 127 in |
| Maximum Truck Clearance | 187 in |
| Shipping Length - Base Machine | 324 in |
| Maximum Operating Height | 198 in |
| Shipping Maximum Height | 118 in |
| Operating Length - Conveyor Up | 594 in |
Service Refill Capacities
| Fuel Tank Capacity | 250.0 gal |
|---|---|
| Water Spray System | 999.9 gal |
Track
| Number of Track Units | 4 |
|---|---|
| Front Track Width | 14 in |
| Rear Track Width | 14 in |
| Front Track Length | 81 in |
| Rear Track Length | 81 in |
Conveyor System
| Discharge Conveyor Width | 36 in |
|---|---|
| Collecting Conveyor Width | 40 in |
| Discharge Conveyor Swing (R/L) | 45 ° |
| Collecting Conveyor Speed | 7.0 mph |
| Discharge Conveyor Maximum Speed | 8.6 mph |
| Discharge Conveyor Swing - From Center | 45 ° |
| Discharge Conveyor Length | 328 in |
Rotary Cutter
| Cutting Width | 83 in |
|---|---|
| Cutting Depth | 12 in |
| Number of Tools | 190 |
| Cutter Diameter | 46 in |
Rotor Assembly
| Maximum Cutting Depth | 12 in |
|---|---|
| Number of Cutting Tools | 190 |
