Challenger
Kubota
B2920
Tractor
23 specifications
Challenger
MT225B
- Operating Weight
- 1,604 lb
- Displacement
- 69 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 22.5 hp
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 1,604 lb |
|---|---|
| Fuel Capacity | 6.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 591 lb |
| 3 Point Hitch Type | Cat.1 |
| Turning Radius | 1,134 in |
Engine
| Displacement | 69 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 22.5 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| PTO Power | 17.6 hp |
Hydraulic System
| Pump Flow Capacity | 8.1 gal/min |
|---|---|
| Relief Valve Pressure | 1,990 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 60 in |
| Overall Length | 9 in |
| Tire Size | (F)6-12 4ply;(R)9.5-16 6ply |
| Width Outside Frame | 49 in |
| Track Width | 36 in |
Transmission
| Max Speed | 13.5 mph |
|---|---|
| Number of Forward Gears | 2 |
| Transmission Type | Hydrostatic (HST) |
