Daedong
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 8,047 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,732 lb |
| 3 Point Hitch Type | Cat. 2 |
| Turning Radius | 181 in |
| Alternator Supplied Amperage | 65 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 3.7 gal |
| Hydraulic System Fluid Capacity | 4.5 gal |
| Engine Oil Capacity | 1.9 gal |
Engine
| Engine Model | 1004.4T |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 82.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 63.4 hp |
Hydraulic System
| Pump Flow Capacity | 10.2 gal/min |
|---|---|
| Relief Valve Pressure | 2,321 psi |
Dimensions
| Height - Top of Cab | 111 in |
|---|---|
| Wheelbase | 94 in |
| Overall Length | 15 in |
| Tire Size | front 12.4R24 rear 16.9R30 |
| Width Outside Frame | 80 in |
Transmission
| Max Speed | 22.6 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | gear |
| Number of Reverse Gears | 4 |
