John Deere
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 10,990 lb |
|---|---|
| Fuel Capacity | 58.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,351 lb |
Engine
| Displacement | 275 in³ |
|---|---|
| Gross Power | 114.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Variable Geometry Turbocharger with Intercooler and Cooled Exhaust Gas |
| Max Torque | 1,033 lb-ft |
| Engine Make | John Deere 4.5L PowerTech PVX |
| PTO Power | 95.3 hp |
Hydraulic System
| Pump Flow Capacity | 21.2 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
| Maximum system pressure | 2,900 psi |
Dimensions
| Wheelbase | 102 in |
|---|---|
| Front Tread Range | 79 in |
| Front Axle Clearance | 21 in |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Number of Reverse Gears | 16 |
