Daedong
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 2,509 lb |
|---|---|
| Fuel Capacity | 7.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,150 lb |
| 3 Point Hitch Type | Cat. I |
| Turning Radius | 113 in |
Engine
| Engine Model | TD1400B-1 |
|---|---|
| Displacement | 85 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 28.5 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.7 gal/min |
|---|
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 65 in |
| Overall Length | 9 in |
| Tire Size | front 7-14 rear 11.2-24 |
| Width Outside Frame | 54 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | constant |
| Number of Reverse Gears | 8 |
