Daewoo
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 6,096 lb |
|---|---|
| Max Speed | 6.8 mph |
| Fuel Capacity | 14.3 gal |
| Tire Size | 10 x 16.5 |
Engine
| Engine Model | D427 |
|---|---|
| Displacement | 165 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 51.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 43 in |
| Width Over Tires | 59 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket | 127 in |
| Clearance at Max Lift and Dump | 88 in |
| Turning Radius from Center - inc bucket | 75 in |
| Turning Radius from Center - machine rear | 63 in |
| Length w/o Bucket | 100 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,499 lb |
| Tipping Angle | 3,946 ° |
| Breakout Force | 3,285 psi |
