Daewoo
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 66.1 gal |
|---|---|
| Tire Size | 17.5 - 25 - 12PR(L-2) |
| Hydraulic System Fluid Capacity | 34.4 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 5.6 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 5.1 gal |
| Rear Axle/Diff Fluid Capacity | 4.9 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Transmission Fluid Capacity | 8.0 gal |
Engine
| Engine Model | DB58T |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 126.0 hp |
| Number of Cylinders | 6 |
| Engine Make | Daewoo |
| Stroke | 5 in |
| Bore | 4 in |
Hydraulic System
| Pump Flow Capacity | 53.1 gal/min |
|---|---|
| Raise Time | 5.2 s |
| Lower Time | 3.3 s |
| Dump Time | 1.3 s |
| Pump Type | Triple tandem vane pump |
| Total cycle | 9.8 s |
Transmission
| Max Speed - Forward | 22.3 mph |
|---|---|
| Max Speed - Reverse | 14.2 mph |
| Transmission Type | Full power-shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
