Daewoo
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Fuel Capacity | 137.4 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 148.0 gal/min |
| Hydraulic System Fluid Capacity | 97.8 gal |
| Hydraulic System Relief Valve Pressure | 4,690 psi |
| Engine Oil Capacity | 7.4 gal |
| Cooling System Fluid Capacity | 13.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
Engine
| Engine Model | DE12T |
|---|---|
| Displacement | 675 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 245.5 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 759 lb-ft |
| Engine Make | 2253 |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 132 in |
| Width to Outside of Tracks | 130 in |
| Removal Counterweight Clearance | 48 in |
| Digging Depth | 302 in |
| Digging Reach | 302 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 61,300 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 278 in |
|---|---|
| Max Reach Along Ground | 411 in |
| Max Loading Height | 272 in |
| Max Vertical Wall Digging Depth | 210 in |
| Max Cutting Height | 395 in |
| Shipping Length of Unit | 441 in |
| Shipping Height of Unit | 141 in |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.39 yd³ |
| Minimum Bucket Capacity | 1.70 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 302 in |
|---|---|
| Max Vertical Wall Digging Depth | 245 in |
| Max Cutting Height | 411 in |
| Max Loading Height | 287 in |
| Max Reach Along Ground | 435 in |
| Shipping Length of Unit | 441 in |
| Shipping Height of Unit | 141 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 335 in |
|---|---|
| Max Cutting Height | 427 in |
| Max Loading Height | 301 in |
| Max Vertical Wall Digging Depth | 276 in |
| Max Reach Along Ground | 467 in |
| Shipping Length of Unit | 441 in |
| Shipping Height of Unit | 141 in |
