Doosan
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 5,703 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 14.1 gal |
| Tire Size | 10-16.5-6PR |
Engine
| Engine Model | A2000 |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 45.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 11.8 gal/min |
|---|---|
| Relief Valve Pressure | 2,538 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 77 in |
| Wheelbase | 39 in |
| Width Over Tires | 59 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 120 in |
| Clearance at Max Lift and Dump | 86 in |
| Turning Radius from Center - inc bucket | 71 in |
| Turning Radius from Center - machine rear | 60 in |
| Length w/o Bucket | 94 in |
Loader
| Operating Load Rating | 1,505 lb |
|---|---|
| Tipping Angle | 3,009 ° |
| Breakout Force | 3,139 psi |
