Doosan
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 6,901 lb |
|---|---|
| Max Speed | 7.8 mph |
| Fuel Capacity | 15.9 gal |
| Tire Size | 12-16.5-8PR |
Engine
| Engine Model | 4TNV98-ZNDS |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 69.9 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 21.7 gal/min |
|---|---|
| Relief Valve Pressure | 3,002 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 80 in |
| Wheelbase | 42 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 29 in |
| Length with Bucket | 130 in |
| Clearance at Max Lift and Dump | 96 in |
| Turning Radius from Center - inc bucket | 76 in |
| Turning Radius from Center - machine rear | 62 in |
| Length w/o Bucket | 102 in |
Loader
| Operating Load Rating | 2,391 lb |
|---|---|
| Tipping Angle | 4,782 ° |
| Breakout Force | 4,678 psi |
