Doosan

DX300LC SLR

Excavator

Max Digging Depth
546 in
Net Power
197.0 hp
All excavators
Doosan DX300LC SLR Excavator
1 / 5
Image 1 of 5
Image: agriexpo.online

Specifications

30 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity132.1 gal
Hydraulic Pump Flow Capacity130.6 gal/min
Hydraulic System Fluid Capacity74.0 gal
Hydraulic System Relief Valve Pressure4,690 psi
Engine Oil Capacity9.6 gal
Cooling System Fluid Capacity9.3 gal
Swing Drive Fluid Capacity1.6 gal

Engine

Engine specifications
Engine ModelDL 08
Displacement466 in³
Power Measured @1,900 rpm
Net Power197.0 hp
TypeT3

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab121 in
Length of Track on Ground158 in
Tail Swing Radius126 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance47 in
Digging Depth546 in
Digging Reach685 in

Undercarriage

Undercarriage specifications
Ground Pressure8 psi
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth546 in
Max Reach Along Ground686 in
Max Loading Height472 in
Max Vertical Wall Digging Depth457 in
Max Cutting Height559 in
Shipping Length of Unit567 in
Shipping Height of Unit137 in

Bucket

Bucket specifications
Reference Bucket Capacity0.90 yd³
