305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 13,779 lb |
|---|---|
| Fuel Capacity | 20.7 gal |
| Hydraulic System Fluid Capacity | 29.4 gal |
| Engine Oil Capacity | 2.7 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Swing Drive Fluid Capacity | 0.4 gal |
Engine
| Engine Model | 4TNV98C |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 59.4 hp |
| Net Power | 58.6 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,365 rpm |
| Max Torque | 178 lb-ft |
| Engine Make | Yanmar |
| Bore | 4 in |
| Stroke | 4 in |
Dimensions
| Height - Top of Cab | 37 in |
|---|---|
| Removal Counterweight Clearance | 25 in |
Undercarriage
| Track Gauge | 62 in |
|---|---|
| Number of Shoes per Side | 39 |
| Drawbar Pull | 12,346 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 246 in |
| Max Vertical Wall Digging Depth | 135 in |
| Max Loading Height | 168 in |
| Shipping Length of Unit | 224 in |
| Shipping Height of Unit | 94 in |
| Max Digging Height | 238 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 9,526 lb-ft |
