Takeuchi
Caterpillar
305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 17,428 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Hydraulic Pump Flow Capacity | 56.1 gal/min |
| Hydraulic System Fluid Capacity | 35.7 gal |
| Hydraulic System Relief Valve Pressure | 4,061 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 2.7 gal |
| Cooling System Fluid Capacity | 3.2 gal |
| Tire Size | 8.25-20-12PR |
| Hydraulic Pump Type | Gear variable |
Engine
| Engine Model | 4TNV98T-ZSTBW |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 71.1 hp |
| Net Torque | 218 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 83 in |
| Overall Width | 8 in |
| Tail Swing Radius | 69 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 161 in |
|---|---|
| Max Cutting Height | 268 in |
| Max Loading Height | 189 in |
| Max Reach Along Ground | 264 in |
| Max Vertical Wall Dig Depth | 127 in |
| Shipping Length of Unit | 250 in |
| Shipping Height of Unit | 118 in |
