DresstaZettelmeyer
ZL5001
Wheel Loader
35 specifications
Dressta
555C
- Operating Weight
- 63,753 lb
- Bucket Capacity - heaped
- 5.49 yd³
- Gross Power
- 335.0 hp
- Net Power
- 319.0 hp
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 63,753 lb |
|---|---|
| Fuel Capacity | 135.0 gal |
| Tire Size | 26.5x2528PR(L-4) |
| Hydraulic System Fluid Capacity | 44.0 gal |
| Static Tipping Weight | 46,508 lb |
| Operating Voltage | 12 V |
| Turning Radius | 287 in |
| Engine Oil Fluid Capacity | 9.0 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 80 A |
| Cooling System Fluid Capacity | 12.0 gal |
| Transmission Fluid Capacity | 19.0 gal |
Engine
| Engine Model | QSM11 |
|---|---|
| Displacement | 660 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 335.0 hp |
| Net Power | 319.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and CAC |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 96.4 gal/min |
|---|---|
| Raise Time | 6.5 s |
| Lower Time | 4.5 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 30 psi |
| Pump Type | Closed with pressure control and vacuum relief |
Dimensions
| Height - Top of Cab | 144 in |
|---|---|
| Width Over Tires | 96 in |
| Length with Bucket on Ground | 355 in |
Transmission
| Max Speed - Forward | 21.7 mph |
|---|---|
| Max Speed - Reverse | 21.7 mph |
| Transmission Type | Electrically controlled full power shift countershaft. |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Bucket Capacity - struck | 4.39 yd³ |
| Dump Clearance at Max Raise | 131 in |
| Breakout Force | 60,010 lb |
| Bucket Width | 138 in |
