Dressta
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 16,768 lb |
|---|---|
| Fuel Capacity | 38.5 gal |
| Cooling System Fluid Capacity | 7.1 gal |
| Engine Oil Capacity | 2.8 gal |
Engine
| Engine Model | 4 10T/240T |
|---|---|
| Displacement | 238 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 80.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 235 lb-ft |
Dimensions
| Height - Top of Cab | 102 in |
|---|---|
| Width Over Tracks | 85 in |
| Length w/ Blade | 170 in |
| Length w/o Blade | 127 in |
Transmission
| Max Speed - Forward | 5.8 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Standard Shoe Size | 387 in |
| Ground Contact Area | 2,463 in³ |
