Dynapac
Tata Hitachi
VM3
Smooth Drum Roller
16 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 41,006 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 84.6 gal |
| Operating Width | 94 in |
Engine
| Engine Model | QSB 6.7 T3 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 190.0 hp |
| Aspiration | water cooled turbo diesel with after cooler |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 10 in |
| Overall Length | 20 in |
| Overall Width | 84 in |
Tires & Wheels
| Tires | 23.1x26 |
|---|
Drum
| Drum Diameter | 62 in |
|---|---|
| Vibration Frequency 1 | 29 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 71,264 lb |
| Vibration Frequency 2 | 31 vpm |
| Centrifugal Force - Low | 51,931 lb |
| Nominal Amplitude - Low | 0 in |
| Frequency | 29 – 31 vpm |
