DynapacDynapac
CA141D
Smooth Drum Roller
13 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 17,858 lb |
|---|---|
| Max Speed | 8.1 mph |
| Fuel Capacity | 31.8 gal |
Engine
| Engine Model | BF4L 2011 |
|---|---|
| Power Measured @ | 2,800 rpm |
| Gross Power | 82.0 hp |
| Aspiration | air cooled turbo diesel |
| Make | Deutz |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 115 in |
| Wheelbase | 11 in |
| Overall Length | 14 in |
| Overall Width | 72 in |
| Turning Radius - Inside | 16 in |
Drum
| Drum Width | 66 in |
|---|---|
| Drum Diameter | 44 in |
| Vibration Frequency 1 | 51 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 20,008 lb |
| Centrifugal Force - Low | 8,768 lb |
| Nominal Amplitude - Low | 0 in |
| Frequency | 51 vpm |
