Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 158.6 gal |
|---|---|
| Tire Size | 18.00-25/32 |
| Engine Oil Capacity | 9.8 gal |
| Cooling System Fluid Capacity | 18.5 gal |
| Hydraulic System Fluid Capacity | 19.9 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | TD 122KE |
|---|---|
| Displacement | 732 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 401.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 1,180 lb-ft |
Weights
| Empty Weight | 50,706 lb |
|---|---|
| Loaded Weight | 122,577 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 50.0 % |
| Weight Distribution Rear - empty | 50.0 % |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 144 in |
| Overall Length | 317 in |
| Overall Width | 143 in |
| Overall Height | 143 in |
| Dump Height | 305 in |
| Dump Ground Clearance | 19 in |
Transmission
| Max Speed | 35.4 mph |
|---|---|
| Transmission Type | planetary |
| Number of Gears - Forward | 5 |
| Number of Gears - Reverse | 5 |
Dump
| Rated Payload | 71,800 lb |
|---|---|
| Dump Angle | 55 ° |
| Load Capacity - heaped | 27.49 yd³ |
| Load Capacity - Struck | 19.10 yd³ |
