Ford
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 8,649 lb |
|---|---|
| Fuel Capacity | 47.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,471 lb |
| Alternator Supplied Amperage | 51 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 15.0 gal |
Engine
| Displacement | 269 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 97.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 278 lb-ft |
| Engine Make | Ford |
| PTO Power | 86.0 hp |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 18.2 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Hydraulic System Type | Open center |
| Maximum system pressure | 2,500 psi |
Dimensions
| Ground Clearance | 21 in |
|---|---|
| Wheelbase | 102 in |
| Overall Length | 152 in |
| Overall Width | 77 in |
| Height - Top of ROPS/FOPS | 111 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Number of Reverse Gears | 2 |
Production
| Series | 10 Series |
|---|---|
| Year Manufactured | 1,982 – 1,990 |
