Ford
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 8,680 lb |
|---|---|
| Fuel Capacity | 6.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 6,208 lb |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
Engine
| Displacement | 305 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 100.0 hp |
| Number of Cylinders | 4 |
| Engine Make | Ford |
| PTO Power | 86.0 hp |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 17.4 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Hydraulic System Type | Open center |
| Maximum system pressure | 2,100 psi |
Dimensions
| Wheelbase | 94 in |
|---|---|
| Overall Length | 162 in |
| Height - Top of ROPS/FOPS | 67 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | EconoShift |
| Number of Reverse Gears | 2 |
Production
| Series | PowerStar 40 Series |
|---|---|
| Year Manufactured | 1,991 – 1,995 |
