Gehl
Case
440
Skid Steer Loader
32 specifications
.png)
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 6,861 lb |
|---|---|
| Hydraulic System Fluid Capacity | 11.9 gal |
| Tire Size | 10.00x16.5 HD |
Engine
| Engine Model | TD2009 |
|---|---|
| Power Measured @ | 2,500 rpm |
| Gross Power | 62.0 hp |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 19.1 gal/min |
|---|
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 42 in |
| Width Over Tires | 62 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket | 127 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 76 in |
| Turning Radius from Center - machine rear | 62 in |
| Length w/o Bucket | 94 in |
Loader
| Operating Load Rating | 1,900 lb |
|---|---|
| Tipping Angle | 3,801 ° |
