Gehl
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 7,380 lb |
|---|---|
| Max Speed | 12.4 mph |
| Fuel Capacity | 19.1 gal |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Tire Size | 12.00x16.5 HD |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | F4M2011 |
|---|---|
| Displacement | 190 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 23.0 gal/min |
|---|
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 81 in |
| Wheelbase | 43 in |
| Width Over Tires | 67 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket | 132 in |
| Clearance at Max Lift and Dump | 94 in |
| Turning Radius from Center - inc bucket | 41 in |
| Turning Radius from Center - machine rear | 33 in |
| Length w/o Bucket | 96 in |
Loader
| Bucket Capacity | 0.80 yd³ |
|---|---|
| Tipping Angle | 4,100 ° |
| Operating Width | 69 in |
