Gehl
Case
440
Skid Steer Loader
32 specifications
.png)
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 8,000 lb |
|---|---|
| Max Speed | 11.9 mph |
| Fuel Capacity | 22.0 gal |
| Hydraulic System Fluid Capacity | 11.0 gal |
| Operating Speed | 8.1 mph |
Engine
| Engine Model | 4TNV98T-ZNMS |
|---|---|
| Displacement | 202 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 84.0 hp |
| Torque Measured @ | 1,650 rpm |
| Max Torque | 215 lb-ft |
Hydraulic System
| Pump Flow Capacity | 21.8 gal/min |
|---|---|
| Relief Valve Pressure | 3,350 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 81 in |
| Wheelbase | 50 in |
| Width Over Tires | 70 in |
| Reach at Max Lift and Dump | 34 in |
| Length with Bucket | 150 in |
| Clearance at Max Lift and Dump | 100 in |
| Turning Radius from Center - inc bucket | 93 in |
| Turning Radius from Center - machine rear | 66 in |
| Length w/o Bucket | 115 in |
Loader
| Operating Load Rating | 2,700 lb |
|---|---|
| Operating Width | 70 in |
