Grove
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| Engine Model | M20S |
|---|---|
| Gross Power | 20.0 hp |
| Fuel Type | Gasoline |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 84 in |
| Overall Length | 14 in |
| Overall Width | 72 in |
| Turning Radius | 181 in |
| Overall Height - mast lowered | 79 in |
Performance
| Operating Weight | 9,901 lb |
|---|---|
| Max Speed | 2.5 mph |
| Tire Size | 8x16.5 Rib |
| Hydraulic System Fluid Capacity | 14.1 gal |
| Tire Fill/Type | Air |
| Fuel Capacity | 8.5 gal |
Platform
| Max Platform Height | 410 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 48 in |
| Platform Inner Width | 30 in |
| Max Working Height | 481 in |
| Max Horizontal Reach | 241 in |
