Hagie
Apache
AS1220
Sprayer
21 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Solution Tank Capacity | 1,199.9 gal |
|---|---|
| Rinse Tank Capacity | 100.0 gal |
| Fuel Capacity | 135.0 gal |
| Dry Weight - min | 28,621 lb |
| Hydraulic Fluid Capacity | 50.0 gal |
Engine
| Displacement | 409 in³ |
|---|---|
| Gross Power | 296.4 hp |
| Engine Make | John Deere PowerTech - 6.8 liters |
| Emission Tier Level | Final Tier 4 |
Dimensions
| Ground Clearance | 72 in |
|---|---|
| Tire Size | 380/105R50 |
Transmission
| Max Speed | 34.8 mph |
|---|
Boom
| Max Adjustable Height | 104 in |
|---|---|
| Min Adjustable Height | 18 in |
| Number of Sections | 9 |
| Plumbing Material | Stainless steel |
