Hamm
Dynapac
CP275
Pneumatic Roller
25 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 50,706 lb |
|---|---|
| Operating weight Cabin | 19,368 lb |
| Operating weight ROPS | 19,059 lb |
| Max Speed | 11.9 mph |
| Fuel Capacity | 62.1 gal |
| Water Spray Tank Fluid Capacity | 51.6 gal |
Engine
| Engine Model | TCD 2012 L04 2V |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 134.2 hp |
| Net Power | 134.2 hp |
| Number of Cylinders | 4 |
| Engine Make | DEUTZ |
| Emissions Certification | EPA Tier 4 |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 143 in |
| Overall Length | 184 in |
| Overall Width | 85 in |
| Height - Top of ROPS/FOPS | 120 in |
| Turning Radius - Inside | 223 in |
| Maximum width | 82,048 in |
Tires & Wheels
| Number of Tires - Front | 4 |
|---|---|
| Number of Tires - Rear | 4 |
| Size of tyres, rear | 11.00-R20 |
| Width over tyres, rear | 72 in |
| Size of tyres, Front | 11.00-R20 |
| Width over tyres, Front | 72 in |
