Haulotte
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| System Voltage | 24 V |
|---|---|
| Battery Amp Hours | 340 |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 73 in |
| Overall Length | 98 in |
| Overall Width | 39 in |
| Overall Height | 98 in |
| Turning Radius | 98 in |
Performance
| Operating Weight | 7,236 lb |
|---|---|
| Max Speed | 1.7 mph |
| Tire Size | 15x5 |
| Hydraulic System Fluid Capacity | 7.0 gal |
Platform
| Max Platform Height | 458 in |
|---|---|
| Max Platform Weight Capacity | 770 lb |
| Max Working Height | 530 in |
| Lift Time | 61.0 s |
| Lower Time | 50.0 s |
| Extended platform length | 128 in |
| Platform Extension length | 36 in |
| Platform length - outside | 93 in |
| Platform width - outside | 39 in |
