Haulotte
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| System Voltage | 48 V |
|---|---|
| Battery Amp Hours | 360 |
| Number of Batteries | 6 |
| Charger Amps | 50 |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 72 in |
| Overall Length | 18 in |
| Overall Width | 53 in |
| Turning Radius | 113 in |
| Overall Height - mast lowered | 79 in |
Performance
| Operating Weight | 13,029 lb |
|---|---|
| Max Speed | 2.8 mph |
| Tire Size | 23x10x12 |
| Hydraulic System Fluid Capacity | 8.0 gal |
| Tire Fill/Type | solid/non marking |
Platform
| Max Platform Height | 395 in |
|---|---|
| Max Platform Weight Capacity | 507 lb |
| Platform Inner Length | 47 in |
| Platform Inner Width | 32 in |
| Max Working Height | 473 in |
| Max Horizontal Reach | 264 in |
| Platform Rotation | 170 ° |
